Rotary Blade Wire Stripping and Twisting Machine

  • Model:KS-W414N
  • Net. Weight:
  • Dimension:
  • Light and portable;

  • Small size, save space;

  • Excellent price/performance ratio;

  • Designed by human structural mechanics to reduce fatigue strength;

  • Easy operation and low technical requirements for operators;

  • Forward and reverse switching function.

  • The cutting depth can be adjusted according to the wire size without replacing the blades.


Download: (1)

Available Wire Type:AC/DC wire, multi-strands copper core wire, electronic wire, etc

Environment Humidity:30%~80%RH(no condensation at 40)

Available Wire Size:OD 1.0~4.0mm(AWG14~22)

Operation Temperature:0~40

Stripping Length:5~20mm

Power Supply:AC220V/50Hz

Air Pressure:0.5~0.7Mpa

Power Rate:60W

Safety Cover:Optional

Net. Weight:10Kg

Dimension(LxWxH):300*200*160mm


Note:

  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
